Custom Hose Assembly
Service
Bespoke hose assemblies made to your exact specifications. Hydraulic, fuel, water, suction/delivery, paint, food grade, steam, and PTFE assemblies. Any length, any fittings, any pressure rating. Same-day service available.
Assembly Types Available
Hydraulic Hose Assemblies
Custom hydraulic assemblies for all pressure ratings and applications
Specs: SAE 100R1, R2, R12, R13, R15, R17 up to 6000 PSI
✓ Construction machinery
✓ Industrial equipment
✓ Agricultural machinery
✓ Transport hydraulics
Suction & Delivery Hose Assemblies
Heavy-duty suction and delivery hose assemblies
Specs: Spiral reinforced, vacuum to 150 PSI
✓ Pumping systems
✓ Liquid transfer
✓ Tank filling
✓ Industrial process
Fuel Hose Assemblies
Petroleum and diesel resistant fuel transfer assemblies
Specs: Chemical resistant, anti-static, up to 150 PSI
✓ Fuel transfer systems
✓ Generator connections
✓ Agricultural machinery
✓ Marine fuel lines
PTFE Hose Assemblies
Chemical resistant PTFE lined assemblies for extreme conditions
Specs: Temperature -70°C to +260°C, chemically inert
✓ Chemical transfer
✓ High temperature
✓ Corrosive fluids
✓ Pharmaceutical
Water Hose Assemblies
Potable and industrial water transfer assemblies
Specs: Food grade available, up to 300 PSI
✓ Pressure washers
✓ Workshops
✓ Factories
✓ Agriculture
Paint Hose Assemblies
Specialized assemblies for paint spray systems and coating applications
Specs: Solvent resistant, smooth bore, up to 300 PSI
✓ Paint spraying
✓ Industrial coating
✓ Body shops
✓ Manufacturing
HOW IT WORKS
1
Tell Us Your Requirements
Hose type, length, pressure rating, fitting types, thread sizes - or send us your old hose
2
We Create Your Assembly
Expert fabrication using quality hoses, precision crimping, and correct fitting selection
3
Fast Delivery or Collection
Same-day collection available, or next-day UK delivery with tracking
Technical specifications
Hose Types
Hydraulic, fuel, water, suction/delivery, paint, food grade, steam, PTFE
Sizes
1/4" through to 4" (6mm to 100mm)
Pressure Ratings
Low pressure (150 PSI) to ultra-high pressure (6000 PSI+)
Temperature Range
-70°C to +260°C depending on hose type
Fittings
All types: JIC, BSP, ORFS, SAE, NPT, Metric, Camlock, Storz
Materials
Steel, stainless steel, brass, aluminum fittings available
Lengths
Any length from 100mm to 50 metres
Certifications
Food grade FDA/EU, pressure test certificates available
All Fitting Types Available
JIC (37° Flare)
Most common hydraulic fitting, high-pressure capable
SAE O-Ring Boss
Straight thread with O-ring, vibration resistant
Toyota
Unique hose Inserts with a BSP thread
BSP (British Parallel)
Standard UK thread
NPT/NPTF (Tapered)
American standard tapered thread
Komatsu
Unique hose Inserts with a metric thread
BSPT (British Tapered)
Self-sealing taper thread, common in UK
Storz
Quick-connect for suction hose and large bore
3000/6000 psi flange
High pressure fittings
ORFS (O-Ring Face Seal)
High-pressure, leak-resistant, no torque required
Metric
ISO metric threads, common on European equipment
Request Custom Assembly Quote
Call, email, or fill in your requirements below
